EMR-ready for direct transfer to medical systems
The MS4980 is designed for customized wireless integration directly into your medical facility's EMR system, or through a gateway if needed. We've optimized the measurement workflow to ensure that the right measurements are being conducted for the right people, and transferred when ready!
1 Establish patient data
Establish patient ID/identifier, so device can quickly scan and save results during measurement procedure.
2 Prepare for measurement
Sterilize platform, and input pre-tare weight deduction if needed.
3 Input user ID and patient ID
Scan user and patient ID (or input manually using touchscreen) to ensure correct person is measured.
4 Conduct weight and / or height measurement
Press "HOLD" to confirm that results are to be saved and transferred after completion.
If digital stadiometer is attached to device, height measurement and BMI calculation will be completed automatically after patient steps onto platform.
If digital stadiometer is attached to device, height measurement and BMI calculation will be completed automatically after patient steps onto platform.
5 Send measurement results to EMR system
Send results to EMR system with a single button press.
6 View results on system
Compare results with previous measurements to analyze trends. Windows 7, 8, and 10 supported.
Specification
| Product model | MS4980 |
| Indicator | DP4800 |
|---|---|
| Capacity | 300 kg / 660 lb |
| Graduation | 100 g / 0.2 lb |
| Dimensions |
Overall:
360 (W) x 480 (D) x 1100 (H) mm
14.2 (W) x 12.2 (D) x 43.3 (H) inch |
|
Platform:
360 (W) x 310 (D) x 70 (H) mm
14.2 (W) x 12.2 (D) x 2.8 (H) inch |
|
|
Column:
1026 mm (40.4 inch)
|
|
| Device Weight | 8.2 kg |
| Power Source |
 Rechargeable Battery Adapter |
Functions
| Product model | MS4980 |
| Functions |
|
|---|---|
| Key Functions | On / Off, Hold / BMI, Tare / Zero, Memory, Pre-tare, Transfer |
| ID Confirmation | NURSE ID, PATIENT ID |
| Data Transmission |
 USB Wireless (optional) |
| Design Features |
 Bubble Level Adjustable Feet Anti-slip Mat |
| Optional Accessories |
 HM201M Mechanical Height Stadiometer HM200D, HM201D Digital Height Stadiometer HM200U Ultrasonic Height Stadiometer AS-9300 Barcode Scanner |
